Appearance |
| Dimensions | 42 mm x 22 mm x 3.88 mm (1.65" x 0.87" x 0.15") |
| Weight | 5 g (0.18 oz) |
| M.2 Type | - 2242-D5-B-M (Double-sided)
|
| Form Factor | |
Interface |
| Bus Interface | |
Storage |
| Capacity | |
| Flash Type | |
Operating Environment |
| Operating Voltage | |
| Operating Temperature | Standard Temp. °C (°F) ~ °C (°F)Extended Temp. °C (°F) ~ °C (°F)Wide Temp. -40°C (-40°F) ~ 85°C (185°F) |
| Storage Temperature | -55°C (-67°F) ~ 85°C (185°F) |
| Humidity | 5% ~ 95% |
| Shock | |
| Vibration (Operating) | 20 G (peak-to-peak), 7 Hz ~ 2000 Hz (frequency) |
Power |
| Power Consumption (Operation) | 2.14 watt(s) |
| Power Consumption (IDLE) | 0.5 watt(s) |
Performance |
| Sequential Read/Write (CrystalDiskMark) | Read: Up to 560 MB/s
Write: Up to 500 MB/s |
| 4K Random Read/Write (IOmeter) | Read: Up to 70,000 IOPS
Write: Up to 85,000 IOPS |
| Mean Time Between Failures (MTBF) | 3,000,000 hour(s) |
| Terabytes Written (TBW) | Up to 1,150 TBW |
| Drive Writes Per Day (DWPD) | 2.05 (3 yrs) |
| Note | - Speed may vary due to host hardware, software, usage, and storage capacity.
- The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
- Terabytes Written (TBW) expresses the endurance under the highest capacity.
|
Warranty |
| Certificate | |
| Warranty | - Three-year Limited Warranty
|
| Warranty Policy | - Please click here for more information about the Transcend Warranty Policy.
- Warranty does not apply when Scope Pro software wear-out indicator displays 0% within the warranty coverage.
- Due to the complexity and variety of industrial applications, Transcend cannot guarantee 100% compatibility with all platforms and under all scenarios. For special applications and environments, it is strongly suggested that you contact Transcend beforehand for clarification.
- Scope Pro software is required by request. Please contact us for more information.
|
