CFast Cards

CFX735 & CFX735I


Transcend's CFX735 CFast card is designed with 112-layer 3D NAND flash and SATA III 6Gb/s interface, featuring high transfer speeds and large capacities, as well as plug-and-play convenience.  The CFX735 can operate stably under -5°C ~ 70°C, and wide-temperature(-40°C ~ 85°C) model can be provided upon request. The CFX735 comes with SLC Mode technology, enhancing flash endurance to 100K P/E cycles while having a sustained write speed that is suitable for write-intensive equipment. Otherwise, the CFX735 includes an Write-Protect Switch—a simple yet powerful tool that instantly safeguards your data. With one quick switch, lock your files from accidental edits, deletions, or unauthorized changes.


Technologies

112-Layer 3D NAND Flash

SLC Mode

Wide Temperature

Dynamic Thermal Throttling

AES Encryption

Read Disturbance

Garbage Collection

Wear Leveling

TRIM

Bad Block Management

Power Shield (PS)

Early Move

Firmware Features

  • Built-in LDPC ECC (Error Correction Code) functionality
  • Advanced Global Wear-Leveling and Block management for reliability
  • Early Move
  • Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
  • TRIM command for better performance
  • NCQ command for better performance
  • Full drive encryption with Advanced Encryption Standard (AES)
  • Power-saving DevSleep (Device Sleep) mode

Hardware Features

  • Compliant with RoHS 2.0 standards
  • Compliant with CFast specification 2.0
  • High-quality 3D NAND flash and SLC mode for exceptional endurance and reliability
  • Durability: 10,000 insertion/removal cycles
  • Power Shield (PS) to ensure data transfer integrity and minimize data corruption in the drive during an abnormal power outage
  • Promised operational reliability in a wide temperature range (from -40°C to 85°C)
  • Write Protect Switch

Specifications

Appearance
Dimensions42.8 mm x 36.4 mm x 3.3 mm (1.69" x 1.43" x 0.13")
Form Factor
  • CFast

Interface
Bus Interface
  • SATA III 6Gb/s

Storage
Flash Type
  • 112-layer 3D NAND flash (SLC mode)
Capacity
  • 20 GB
  • 40 GB
  • 80 GB
  • 160 GB
  • 320 GB

Operating Environment
Operating Voltage
  • 3.3V±5%
Operating Temperature
  • Standard Temp.
    -5°C (23°F) ~ 70°C (158°F)
  • Extended Temp.
    °C (°F) ~ °C (°F)
  • Wide Temp.
    -40°C (-40°F) ~ 85°C (185°F)
Storage Temperature-40°C (-40°F) ~ 85°C (185°F)
Humidity0% ~ 95%
Shock
  • 15 G, 11 ms, 3 axis
Vibration (Operating)3 G (peak-to-peak), 5 Hz ~ 800 Hz (frequency)

Power
Power Consumption (Max.)1.2 watt(s)

Performance
Read Speed (Max.)Up to 550 MB/s
Write Speed (Max.)Up to 520 MB/s
Mean Time Between Failures (MTBF)3,000,000 hour(s)
Note
  • Speed may vary due to host hardware, software, usage, and storage capacity.

Warranty
Certificate
  • CE
  • UKCA
  • FCC
  • ICES
  • BSMI
Warranty
  • Three-year Limited Warranty
Warranty Policy
  • Please click here for more information about the Transcend Warranty Policy.
  • Due to the complexity and variety of industrial applications, Transcend cannot guarantee 100% compatibility with all platforms and under all scenarios. For special applications and environments, it is strongly suggested that you contact Transcend beforehand for clarification.

Order Information

20GB
  • TS20GCFX735
  • TS20GCFX735I
40GB
  • TS40GCFX735
  • TS40GCFX735I
80GB
  • TS80GCFX735
  • TS80GCFX735I
160GB
  • TS160GCFX735
  • TS160GCFX735I
320GB
  • TS320GCFX735
  • TS320GCFX735I
