microSD Cards

Industrial Temp UHS-I U1 microSDHC220I card

Transcend's SuperMLC technology is a cost-effective solution that offers performance close to that of SLC NAND flash at a more affordable price. These industrial-grade SuperMLC microSD cards combine the advantages of high-performance, exceptional endurance, and wide temperature tolerance (-40°C to 85°C) at affordable prices, making them ideal for write-intensive applications such as medical devices, surveillance systems, and POS terminals.

Share

Features

  • Manufactured with industrial SuperMLC technology
  • Excellent endurance
  • Cost-effective solution
  • Operating Temperature: -40 ~ 85°C
  • RoHS compliant
  • Compatible with SD Specification Ver. 3.01
  • Supports S.M.A.R.T. function
  • Built-in ECC (Error Correction Code) functionality

Specifications

Interface (connector) microSD flash card connector
Form Factor microSDHC flash card
Flash Type SuperMLC
Capacity 4GB / 8GB/ 16GB / 32GB
Max. R/W Performance (Vary by density)* Read: 95MB/s, Write: 75MB/s
Op. Voltage 2.7V~3.6V
Power Consumption 0.72W
Op. Temp. -40℃~85℃
Storage Temp. -40℃~85℃
Humidity 0%~95%
Shock Acceleration 490m/s^ 2; standard holding time 11 ms, semi-sine wave, velocity change 3.44 m/s
Vibration Operating: 20G (Peak-to-Peak), 20Hz to 2000Hz (Frequency)
Dimensions 11mm × 15mm × 1mm (0.43" x 0.59" x 0.04")
Terabytes Written Up to 600*
*Performance may vary by testing environment and methods.
Warranty Two-year Limited Warranty
*Please access here for more information about Transcend Warranty Policy.
*Note Speed may vary due to host hardware, software and usage.

Due to the complexity and variety of industrial applications, Transcend cannot guarantee 100% compatibility with all platforms and under all scenarios.
For special applications and environments, it is strongly suggested to contact Transcend beforehand for clarification.


Order Information

4GB
  • TS4GUSD220I
8GB
  • TS8GUSD220I
16GB
  • TS16GUSD220I
32GB
  • TS32GUSD220I
